> Adopts 12MP/8MP/5MP/2MP progressive CMOS, provides 12MP 25FPS/8MP 30FPS/5MP 30FPS/2MP 60FPS/2MP 30FPS Stream.
> 140dB WDR, 0.001 Lux min. illumination.
> 2.7-13.5mm motorized lens with auto Iris.
> 24pcs of SMD IR, IR distance up to 40m.
> PoE&DC12V.
> Built-in waterproof high quality microphone (-32dB).
> Built-in micro SD slot for local recording, supporting Max. 128GB.
> Built-in hardware reset.
> Audio 1in/1out, alarm 1in/1out.
> IP67&IK10, -50°C ~65°C working temperature.
> Customizable Video Analysis Based on NPU
Recognition: Human/Face/Vehicle/License Plate/Pet/Object Detection and Recognition
Enhanced Detection: People Counting/Loitering/Object Left/Object Missing
Perimeter Protection: Tripwire/Intrusion by human or vehicle
Smart MD: Motion/Human/Vehicle
| Model | IPC-MG1P-71201-ZA | IPC-MG1P-7801-ZA | IPC-MG1P-7501-ZA | IPC-MG1P-7201-ZA | IPC-MG1P-7221-ZA |
| Camera | |||||
| Main Solution | SSC379G+OS 12D | SSC339G+IMX415 | SSC338G+IMX335 | SSC338G+IMX462 | SSC336Q+IMX462 |
| Image Sensor CMOS | 1/2.49’’ 12Megapixel | 1/2.8’’ 8Megapixel | 1/2.8’’ 5Megapixel | 1/2.8’’ 2Megapixel | 1/2.8’’ 2Megapixel |
| Effective Pixels | 4512*2512 | 3840*2160 | 2592*1944 | 1920*1080 | 1920*1080 |
| Min. Illumination | 0.001Lux @ (F1.8, AGC ON), 0 Lux with IR ON | ||||
| Shutter | 1/2s-1/50,000s | ||||
| Lens | 2.7-13.5mm motorized lens with auto Iris | ||||
| Day&Night | IR-CUT Auto Switch, Manual Switch, Timing Switch | ||||
| DNR | 3D Digital Noise Reduction | ||||
| WDR | Yes, real WDR 140dB | ||||
| Compression Standard | |||||
| Codec | H.265+/H.264+/H.265/H.264/MJPEG. | ||||
| Data Rate -Main | 256-16000kbps | 256-16000kbps | 256-8000kbps | 256-8000kbps | 256-8000kbps |
| Data Rate -Sub | 50-1000kbps | 50-1000kbps | 50-1000kbps | 50-1000kbps | 50-1000kbps |
| Audio Compression | G.711A/G.711U/AAC/PCM/G.726 | ||||
| Audio Record | Yes | ||||
| Image | |||||
| Max. Resolution | 12MP(4512*2512) | 8MP(3840*2160) | 5MP(2592*1944) | 2MP(1920*1080) | 2MP(1920*1080) |
| Frame Rate | 25FPS | 30/25FPS | 30/25FPS | 60/50FPS | 30/25FPS |
| Features | DWDR, 3D DNR, AGC, MGC, AWB, ROI, Motion Detection, Privacy Masking | ||||
| Image Adjustment | Mirroring, Saturation, Brightness, Sharpness, Contrast Adjustment, Exposure, DWDR, Shutter, IRIS, LDC etc. | ||||
| Network | |||||
| Protocols | TCP/IP, UDP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP; SNMP v1/v2/v3, IEEE802.1X, IPv4/v6; Bonjour; SIP, ICMP, IGMP, QoS, SSL/TLS; | ||||
| Compatibility | ONVIF (Profile S/Profile G/ Profile T); CGI; | ||||
| HIKVISION/Dahua/XM; | |||||
| RTMP, RTSP, NFS, VoIP, TS streaming | |||||
| HTTP Streaming/HTTP Notification | |||||
| AI Features | Customizable Video Analysis Based on NPU | ||||
| Recognition: Human/Face/Vehicle/License Plate/Pet/Object Detection and Recognition | |||||
| Enhanced Detection: People Counting/Loitering/Object Left/Object Missing | |||||
| Perimeter Protection: Tripwire/Intrusion by human or vehicle | |||||
| Smart MD: Motion/Human/Vehicle | |||||
| Interface | |||||
| Network | RJ-45 LAN Port | ||||
| POE | Yes, Built-in POE | ||||
| Audio | Built-in Microphone, line audio 1in/1out | ||||
| Alarm | Alarm in/out | ||||
| Local Recording | Built-in micro SD slot for local recording, supporting max. 128GB | ||||
| Hardware Reset | Yes, Built-in reset button | ||||
| General | |||||
| Color | White | ||||
| Accessories | Printed User Manual, Installation Kits, CD or Download Link QR Code Stickers | ||||
| Power Supply | PoE&DC12V | ||||
| Work Humidity | 10%-90% | ||||
| Operation Temperature | -50℃-65℃ | ||||
| Surge Protection | External/Built-in SPD | ||||
| Proof | Metal; IP67&IK10; for both indoor & outdoor. | ||||
| Power Consumption | Max. 17W | ||||
| Size | Φ116*91mm | ||||
| Weight | N.W.: 590g, G.W.: 690g | ||||
| * We may adopt the backup solution when the main solution chipset is in shortage. | |||||
| We reserve the right to change products and specifications without prior notice. This information does not convey any license by any implication or otherwise under any patents or other rights. | |||||
