> Adopts 8MP/5MP/4MP/2MP progressive CMOS, provides 8MP 30FPS/5MP 30FPS/4MP 30FPS/2MP 60FPS/2MP 30FPS Stream.
> 140dB WDR, 0.001 Lux min. illumination.
> 2.7-13.5mm motorized lens with auto Iris.
> 4pcs of array IR, IR distance up to 70m.
> PoE&DC12V.
> Built-in waterproof high quality microphone (-32dB).
> Built-in micro SD slot for local recording, supporting Max. 128GB.
> Built-in hardware reset.
> Audio 1in/1out, alarm 1in/1out.
> IP67&IK10, -50°C ~65°C working temperature.
> Customizable Video Analysis Based on NPU
Recognition: Human/Face/Vehicle/License Plate/Pet/Object Detection and Recognition
Enhanced Detection: People Counting/Loitering/Object Left/Object Missing
Perimeter Protection: Tripwire/Intrusion by human or vehicle
Smart MD: Motion/Human/Vehicle
| Model | IPC-MGA-7801-Z | IPC-MGA-7501-Z | IPC-MGA-7401-Z | IPC-MGA-7201-Z | IPC-MGA-7221-Z |
| Camera | |||||
| Main Solution | SSC339G+IMX415 | SSC338G+IMX335 | SSC30KQ+SC400AI | SSC338G+IMX462 | SSC336Q+IMX462 |
| Backup Solution * | T40XP+IMX415 | T40XP+SC500AI | T40XP+SC400AI | T40N+IMX462 | T40N+IMX462 |
| Image Sensor CMOS | 1/2.8’’ 8Megapixel | 1/2.8’’ 5Megapixel | 1/3’’ 4Megapixel | 1/2.8’’ 2Megapixel | 1/2.8’’ 2Megapixel |
| Effective Pixels | 3840*2160 | 2592*1944 | 2688*1520 | 1920*1080 | 1920*1080 |
| Min. Illumination | 0.001Lux @ (F1.8, AGC ON), 0 Lux with IR ON | ||||
| Shutter | 1/2s-1/50,000s | ||||
| Lens | 2.7-13.mm motorized lens with auto Iris | ||||
| Day&Night | ICR, Smart IR, Controllable IR LEDs | ||||
| DNR | 3D Digital Noise Reduction | ||||
| WDR | Yes, real WDR 140dB | ||||
| Compression Standard | |||||
| Codec | H.265+/H.264+/H.265/H.264/MJPEG. | ||||
| Data Rate -Main | 256-16000kbps | 256-8000kbps | 256-8000kbps | 256-8000kbps | 256-8000kbps |
| Data Rate -Sub | 50-1000kbps | 50-1000kbps | 50-1000kbps | 50-1000kbps | 50-1000kbps |
| Audio Compression | G.711A/G.711U/AAC/PCM/G.726 | ||||
| Audio Record | Yes | ||||
| Image | |||||
| Max. Resolution | 8MP(3840*2160) | 5MP(2592*1944) | 4MP(2688*1520) | 2MP(1920*1080) | 2MP(1920*1080) |
| Frame Rate | 30/25FPS | 30/25FPS | 30/25FPS | 60/50FPS | 30/25FPS |
| Features | DWDR, 3D DNR, AGC, MGC, AWB, ROI, Motion Detection, Privacy Masking | ||||
| Image Adjustment | Mirroring, Saturation, Brightness, Sharpness, Contrast Adjustment, Exposure, DWDR, Shutter, IRIS, LDC etc. | ||||
| Network | |||||
| Protocols | TCP/IP, UDP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP; SNMP v1/v2/v3, IEEE802.1X, IPv4/v6; Bonjour; SIP, ICMP, IGMP, QoS, SSL/TLS; | ||||
| Compatibility | ONVIF (Profile S/Profile G/ Profile T); CGI; HIKVISION/Dahua/XM; RTMP, RTSP, NFS, VoIP, TS streaming HTTP Streaming/HTTP Notification |
||||
| AI Features | Customizable Video Analysis Based on NPU Recognition: Human/Face/Vehicle/License Plate/Pet/Object Detection and Recognition Enhanced Detection: People Counting/Loitering/Object Left/Object Missing Perimeter Protection: Tripwire/Intrusion by human or vehicle Smart MD: Motion/Human/Vehicle |
||||
| Interface | |||||
| Network | RJ-45 LAN Port | ||||
| POE | Yes, Built-in POE | ||||
| Audio | Built-in Microphone, line audio 1in/1out | ||||
| Alarm | Alarm in/out | ||||
| Local Recording | Built-in micro SD slot for local recording, supporting max. 128GB | ||||
| Hardware Reset | Yes, Built-in reset button | ||||
| General | |||||
| Color | White | ||||
| Accessories | Printed User Manual, Installation Kits, CD or Download Link QR Code Stickers | ||||
| Power Supply | PoE&DC12V | ||||
| Work Humidity | 10%-90% | ||||
| Operation Temperature | -50℃-65℃ | ||||
| Surge Protection | External/Built-in SPD | ||||
| Proof | Metal; IP67&IK10; for both indoor & outdoor. | ||||
| Power Consumption | Max. 17W | ||||
| Size | mm | ||||
| Weight | N.W.: g, G.W.: g | ||||
| * We may adopt the backup solution when the main solution chipset is in shortage. We reserve the right to change products and specifications without prior notice. This information does not convey any license by any implication or otherwise under any patents or other rights. |
|||||
