> Adopts 5MP/4MP/2MP progressive CMOS, provides 5MP 30FPS/4MP 30FPS/2MP 60FPS/2MP 30FPS Stream.
> 140dB WDR, 0.001Lux min. illumination.
> F1.0, 2.7-13.5mm motorized lens with auto Iris.
> No LED, visual 30-50m
> PoE&DC12V.
> Built-in waterproof high quality microphone (-32dB).
> Built-in micro SD slot for local recording, supporting Max. 128GB.
> Built-in hardware reset.
> Audio 1in/1out, alarm 1in/1out.
> IP67&IK10, -50°C ~65°C working temperature.
> Customizable Video Analysis Based on NPU
Recognition: Human/Face/Vehicle/License Plate/Pet/Object Detection and Recognition
Enhanced Detection: People Counting/Loitering/Object Left/Object Missing
Perimeter Protection: Tripwire/Intrusion by human or vehicle
Smart MD: Motion/Human/Vehicle
| Model | IPC-MG1P-7501-ZC | IPC-MG1P-7401-ZC | IPC-MG1P-7201-ZC | IPC-MG1P-7221-ZC |
| Camera | ||||
| Main Solution | SSC338G+IMX335 | SSC338G+IMX347 | SSC338G+IMX462 | SSC336Q+IMX462 |
| Image Sensor CMOS | 1/2.8’’ 5Megapixel | 1/1.8’’ 4Megapixel | 1/2.8’’ 2Megapixel | 1/2.8’’ 2Megapixel |
| Effective Pixels | 2592*1944 | 2592*1440 | 1920*1080 | 1920*1080 |
| Min. Illumination | 0.001Lux @ (F1.2, AGC ON) | |||
| Shutter | 1/2s-1/50,000s | |||
| Lens | F1.0, 2.7-13.mm motorized lens with auto Iris | |||
| Day&Night | Full Time Color Image | |||
| DNR | 3D Digital Noise Reduction | |||
| WDR | Yes, real WDR 140dB | |||
| Compression Standard | ||||
| Codec | H.265+/H.264+/H.265/H.264/MJPEG. | |||
| Data Rate -Main | 256-8000kbps | 256-8000kbps | 256-8000kbps | 256-8000kbps |
| Data Rate -Sub | 50-1000kbps | 50-1000kbps | 50-1000kbps | 50-1000kbps |
| Audio Compression | G.711A/G.711U/AAC/PCM/G.726 | |||
| Audio Record | Yes | |||
| Image | ||||
| Max. Resolution | 5MP(2592*1944) | 4MP(2592*1440) | 2MP(1920*1080) | 2MP(1920*1080) |
| Frame Rate | 30/25FPS | 30/25FPS | 60/50FPS | 30/25FPS |
| Features | DWDR, 3D DNR, AGC, MGC, AWB, ROI, Motion Detection, Privacy Masking | |||
| Image Adjustment | Mirroring, Saturation, Brightness, Sharpness, Contrast Adjustment, Exposure, DWDR, Shutter, IRIS, LDC etc. | |||
| Network | ||||
| Protocols | TCP/IP, UDP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP; SNMP v1/v2/v3, IEEE802.1X, IPv4/v6; Bonjour; SIP, ICMP, IGMP, QoS, SSL/TLS; | |||
| Compatibility | ONVIF (Profile S/Profile G/ Profile T); CGI; | |||
| HIKVISION/Dahua/XM; | ||||
| RTMP, RTSP, NFS, VoIP, TS streaming | ||||
| HTTP Streaming/HTTP Notification | ||||
| AI Features | Customizable Video Analysis Based on NPU | |||
| Recognition: Human/Face/Vehicle/License Plate/Pet/Object Detection and Recognition | ||||
| Enhanced Detection: People Counting/Loitering/Object Left/Object Missing | ||||
| Perimeter Protection: Tripwire/Intrusion by human or vehicle | ||||
| Smart MD: Motion/Human/Vehicle | ||||
| Interface | ||||
| Network | RJ-45 LAN Port | |||
| POE | Yes, Built-in POE | |||
| Audio | Built-in Microphone, line audio 1in/1out | |||
| Alarm | Alarm in/out | |||
| Local Recording | Built-in micro SD slot for local recording, supporting max. 128GB | |||
| Hardware Reset | Yes, Built-in reset button | |||
| General | ||||
| Color | White | |||
| Accessories | Printed User Manual, Installation Kits, CD or Download Link QR Code Stickers | |||
| Power Supply | PoE&DC12V | |||
| Work Humidity | 10%-90% | |||
| Operation Temperature | -50℃-65℃ | |||
| Surge Protection | External/Built-in SPD | |||
| Proof | Metal; IP67&IK10; for both indoor & outdoor. | |||
| Power Consumption | Max. 17W | |||
| Size | Φ116*91mm | |||
| Weight | N.W.: 590g, G.W.: 690g | |||
| * We may adopt the backup solution when the main solution chipset is in shortage. | ||||
| We reserve the right to change products and specifications without prior notice. This information does not convey any license by any implication or otherwise under any patents or other rights. | ||||
