> Adopts 8MP/5MP/2MP progressive CMOS, provides 8MP 20FPS/5MP 30FPS/2MP 30FPS Stream.
> WDR, 0.001 Lux min. illumination.
> 8MP: 5.35-96.3 mm, 20X Optical Zoom.
> 5MP: 5.35-96.3 mm, 20X Optical Zoom.
> 2MP: 5.35-96.3 mm, 20X Optical Zoom.
> Horizontal rotation: 360° endless, 0.1° ~ 200°/s;
> Vertical rotation: -10° - 90°, 0.1° ~ 180°/s;
> Suport 256 presets; 3 patrols, support maximum 64 presets;
> Audio in / out, Alarm in / out.
> Built-in micro SD slot, up to 256GB.
> Built-in hardware reset.
> POE&DC12V.
> -40°C ~60°C working temperature.
> Smart Detection based on CV
Detection: Face/Human/Vehicle/License Plate
Perimeter Protection: Tripwire/Intrusion by human or vehicle
Smart MD: Motion/Human/Vehicle
| Model | IPC-MP4S-5811-Z20 | IPC-MP4S-5511-Z20 | IPC-MP4S-5211-Z20 | BVH-MP4S-3251-Z20 | BVH-MP4S-3231-Z20 |
| Camera | |||||
| Main Solution | SSC338Q+SC8238 | SSC338Q+SC500AI | SSC336Q+SC200AI | SSC337DE+IMX335 | SSC335+IMX307 |
| Image Sensor CMOS | 1/2.8” 2Megapixel | ||||
| Effective Pixels |
3840x2160 |
2592x1944 | 1920×1080 | 2592x1944 | 1920×1080 |
| Min. Illumination | 0. 001Lux (F1.6, Color), 0 Lux (F1.6, IR ON) | ||||
| Shutter | 1/2s-1/50,000s | ||||
| Lens | 45.35-96.3 mm (20x optical zoom) | ||||
| Day&Night | IR-CUT Auto Switch, Manual Switch, Timing Switch | ||||
| DNR | 3D Digital Noise Reduction | ||||
| WDR | Yes, real WDR 120dB | ||||
| Compression Standard | |||||
| Codec | H.265+, H.264+, H.265, H.264, MJPEG | ||||
| Data Rate -Main | 256-8000kbps | ||||
| Data Rate -Sub | 50-1000kbps | ||||
| Audio Compression | G.711A/G.711U/AAC/PCM/G.726 | ||||
| Audio Record | Yes | ||||
| Image | |||||
| Max. Resolution | 8MP(3840*2160) | 5MP(2560*1920) | 2MP(1920*1080) | 5MP(2560*1920) | 2MP(1920*1080) |
| Frame Rate | 20FPS | 30FPS | 60FPS | 30FPS | 30FPS |
| Features | Image Settings, Mirroring, Defog, ROI, etc. | ||||
| AI Features | Smart Detection based on CV | ||||
| Detection/Recognition: Face/Human/Vehicle/License Plate | |||||
| Perimeter Protection: Tripwire/Intrusion by human or vehicle | |||||
| Smart MD: Motion/Human/Vehicle | |||||
| Network | |||||
| Protocols | TCP/IP,HTTP,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,PPPoE,UPnP,SMTP |
||||
| Compatibility | HTTPCGI,ONVIF(ProfileS,ProfileG,ProfileT) | ||||
|
AI Features |
Smart Detection based on CV | ||||
| Detection: Face/Human/Vehicle/License Plate | |||||
| Perimeter Protection: Tripwire/Intrusion by human or vehicle | |||||
| Smart MD: Motion/Human/Vehicle | |||||
| Interface | |||||
| Network | RJ-45 10M/100M LAN Port | ||||
| Hardwork Reset | Yes, build in reset button | ||||
| Audio | Yes, in/out | ||||
| Alarm | Yes, in/out | ||||
| Local Recording | Built-in micro SD slot, up to 256GB | ||||
| General | |||||
| Color | White&Black | ||||
| Accessories | Printed User Manual, Installation Kits | ||||
| Power Supply | PoE&DC12V | ||||
| Operation Temperature | -40℃-60℃ | ||||
| Proof | IP66&IK10 | ||||
| Power Consumption | Max. 5.5W | ||||
| Size | Φ71.8*118mm | ||||
| Weight |
N.W.: 350g, G.W.: 450g |
|
|
||
| * We may adopt the backup solution when the main solution chipset is in shortage. | |||||
| * We reserve the right to change products and specifications without prior notice. This information does not convey any license by any implication or otherwise under any patents or other rights. | |||||
