> Adopts 4MP/2MP progressive CMOS, provides 4MP 30FPS/4MP 30FPS Stream.
> WDR, 0.01 Lux min. illumination.
> 2.8mm/3.6mm fixed lens.
> 6pcs of IR, IR distance up to 10m.
> WiFi&DC5V, power adaptor included in the package.
> Built-in microphone and speaker for two-way talk.
> Built-in micro SD slot for local recording.
> Look at your home at any time and from anywhere with remote live video streaming via mobile App.
> -10°C ~50°C working temperature.
> Smart Detection based on CV
Detection: Human/Vehicle Detection/Package Detection/Face Detection/Pet Detection/PIR Detection
Baby Crying Detection optional.
| TECHNICAL SPECIFICATIONS | ||
| Model | IPC-J6-400W | IPC-J6-200W |
| Solution | SSC375+CV4002 | SSC373+CV2003 |
| Video and Audio | ||
| Image Sensor | 1/3" CMOS sensor, 4MP, 1440P | 1/3" CMOS sensor, 2MP, 1080P |
| Max. Resolution | 1440P (2560*1440) | 1080P (1920*1080) |
| Frame Rate | Mainstream: 30fps, Substream: 30fps | Mainstream: 30fps, Substream: 30fps |
| Lens | F1.6 2.8mm, fixed | F1.6 2.8mm, fixed |
| Field of View | Horizontal: 100° Vertical: 55° Diagonal: 120° | Horizontal: 100° Vertical: 55° Diagonal: 120° |
| Infrared Night Vision | Up to 10 m (33 ft), auto-switching with IR-cut filter | |
| Audio | Two-way audio (with noise reduction and echo suppression technology) | |
| Power | ||
| Wired-Power | DC5V, USB Type-C cable and adaptor are included | |
| Interfaces | ||
| Local Storage | Built-in micro SD slot, supporting Max. 512GB microSD card | |
| Indicate LED | Yes, 2 colors | |
| Reset/Power button | Yes | |
| Wi-Fi | ||
| Wireless Standard | IEEE802.11b/g/n default, IEEE802.11b/g/n/ax optional | |
| Operating frequency | 2.4GHz default; 2.4GHz&5GHz dual band optional | |
| Wireless security | WPA/WPA2, secured | |
| Software | ||
| OS Supported | PC: Windows and Mac OS; Smartphone: iOS and Android; work with our home recorder VG-miniN1 by Kits; | |
| Protocols & Standards | SSL, TCP/IP, UDP, UPNP, SMTP, NTP, P2P, WebRTC, MQTT | |
| Storage | Storage in Cloud, storage locally with micro SD card, storage locally with our home recorders (VG-miniN1, VG-N100PRO) | |
| Bluetooth | BLE v5.0 optional | |
| Other Features | ||
| Smart Alarm | PIR Detection; Human Detection; Vehicle Detection; Pet Detection; Package Detection; Face Detection | |
| Recording Mode | Smart alarm triggered recording; 7*24 recording | |
| Time Lapse | Yes | |
| Smart Home Compatibility | Google Assistant, Amazon Alexa | |
| Notifications | Smart alarm triggered notifications | |
| Work Environment | ||
| Operating Temperature | -10°C~50°C | |
| Operating Humidity | 10% ~ 90% | |
| Weatherproof | Indoor | |
| Mechanical | ||
| Dimensions | 116.52*58*32mm | |
| Weight | 250g | |
| We reserve the right to change products and specifications without prior notice. This information does not convey any license by any implication or otherwise under any patents or other rights. | ||
