> Adopts 5MP/2MP progressive CMOS, provides 5MP 25FPS/2MP 30FPS Stream;
> 2.8mm/3.6mm fixed lens;
> 6 pcs of SMD LEDs for clear night vision, IR distance up to 10 meters;
> WiFi 2.4GHz IEEE802.11b/g/n;
> USB DC5V, power adaptor included;
> Built-in microphone and speaker, two-way intercom supported;
> Built-in micro SD slot, supporting maximum 256GB;
> Built-in hardware reset;
> 3D DNR, WDR, BLC;
> -10°C ~50°C working temperature.
> Smart Detection based on CV
Detection: Human/Vehicle Detection
Perimeter Protection: Tripwire/Intrusion by human or vehicle
Smart MD: Motion/Human/Vehicle
Face Detction / Baby Crying detection / Pet Detection optional.
Model |
IPC-J5T-1500 |
IPC-J5T-1200 |
Camera |
||
Main Solution |
T31X+GC4653 |
T31N+GC2063 |
Image Sensor CMOS |
1/3’’ 5Megapixel |
1/2.9’’ 2Megapixel |
Effective Pixels |
2592*1944 |
1920*1080 |
Min. Illumination |
0.01Lux @ (F1.8, Color), 0 Lux (F1.8, IR ON) |
|
Shutter |
1/2s-1/50,000s |
|
Lens |
2.8/3.6mm fixed lens |
|
Day&Night |
IR-CUT Auto Switch, Manual Switch, Timing Switch |
|
DNR |
3D Digital Noise Reduction |
|
WDR |
Yes, Digital WDR |
|
Compression Standard |
||
Codec |
H.265/H.264/MJPEG. |
|
Data Rate -Main |
256-8000kbps |
256-8000kbps |
Data Rate -Sub |
50-1000kbps |
50-1000kbps |
Audio Compression |
G.711A/G.711U/AAC/PCM/G.726 |
|
Audio Record |
Yes |
|
Image |
||
Max. Resolution |
5MP(2592*1944) |
2MP(1920*1080) |
Frame Rate |
25FPS |
30FPS |
Features |
DWDR, 3D DNR, AGC, MGC, AWB, ROI, Motion Detection, Privacy Masking |
|
Image Adjustment |
Mirroring, Saturation, Brightness, Sharpness, Contrast Adjustment, Exposure, DWDR, Shutter, IRIS, LDC etc. |
|
Network |
||
Protocols |
TCP/IP, HTTP, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, |
|
Compatibility |
HTTP CGI, ONVIF |
|
Interface |
||
Network |
RJ-45 LAN Port |
|
Wifi |
Yes, 2.4GHz single band as default, 2.4GHz&5GHz dual band optional |
|
Audio |
Built-in Microphone |
|
Alarm |
Alarm in/out |
|
Local Recording |
Built-in micro SD slot, supporting max. 256GB |
|
Hardware Reset |
Yes |
|
General |
||
Color |
White&Black |
|
Accessories |
Printed User Manual, Installation Kits |
|
Power Supply |
USB DC5V, power adaptor included |
|
Work Humidity |
10%-90% |
|
Operation Temperature |
-10℃-50℃ |
|
Waterproof |
Indoor |
|
Power Consumption |
Max. 5.5W |
|
Size |
Φ*mm |
|
Weight |
N.W. g, G.W. g |
|
We reserve the right to change products and specifications without prior notice. This information does not convey any license by any implication or otherwise under any patents or other rights. |
