> Adopts 2 megapixel progressive CMOS, provides 2MP(1920*1080)@30FPS Stream.
> 1/3” 2Megapixel progressive scan CMOS.
> Built-in 2.8/3.6mm fixed lens.
> 24pcs of SMD IR LEDS, IR distance up to 30m.
> PoE&DC12V.
> Built-in waterproof high quality microphone (-32dB).
> Built-in Micro SD slot for local recording, supporting max. 512GB.
> Built-in hardware reset.
> 3DNR, AWB, AGC, BLC, Defog, ROI.
> Real WDR 120dB.
> IP67
> Accurate Smart Detection with AI Chipset: Face Detection/Human Detection/Vehicle Detection/Non-Motor Vehicle Detection/Smart Motion Detection/Line-Crossing Detection/Zone-Intrusion Detection/Abnormal Audio Detection/Pet Detection/Fire and Smoke Detection.
| Model | IPC-MH1-2560 | IPC-MH1-2260 |
| Camera | ||
| Main Solution | SSC377+CV4002 | SSC377+SC231AH |
| Image Sensor CMOS | 1/2.8’’ 5Megapixel | 1/3’’ 2Megapixel |
| Effective Pixels | 2560*1920 | 1920*1080 |
| Min. Illumination | 0.01Lux @ (F1.2, AGC ON), 0 Lux with IR ON | |
| Shutter | 1/2s-1/50,000s | |
| Lens | 2.8/3.6mm fixed lens | |
| Day&Night | ICR, Smart IR, Controllable IR LEDs | |
| DNR | 3D Digital Noise Reduction | |
| WDR | Yes, digital WDR | |
| Compression Standard | ||
| Codec | H.265+/H.264+/H.265/H.264/MJPEG | |
| Data Rate -Main | 256-12000kbps | 256-8000kbps |
| Data Rate -Sub | 50-2048kbps | 50-2048kbps |
| Audio Compression | G.711A/G.711U/AAC/PCM/G.726 | |
| Audio Record | Yes | |
| Image | ||
| Max. Resolution | 5MP(2560*1920) | 2MP(1920*1080) |
| Frame Rate | 30FPS | 30FPS |
| Features | WDR, 3D DNR, AGC, MGC, AWB, ROI, Motion Detection, Privacy Masking | |
| Image Adjustment | Mirroring, Saturation, Brightness, Sharpness, Contrast Adjustment, Exposure, DWDR, Shutter, IRIS, LDC etc. | |
| Network | ||
| Protocols | TCP/IP, UDP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP; SNMP v1/v2/v3, IEEE802.1X, IPv4/v6; Bonjour; SIP, ICMP, IGMP, QoS, SSL/TLS; | |
| Compatibility | ONVIF (Profile S/Profile G/ Profile T); CGI; | |
| HIKVISION/Dahua/XM; | ||
| RTMP, RTSP, NFS, VoIP, TS streaming | ||
| HTTP Streaming/HTTP Notification | ||
| AI Features |
Accurate Smart Detection with AI Chipset: Face Detection/Human Detection/Vehicle Detection/Non-Motor Vehicle Detection/Smart Motion Detection/Line-Crossing Detection/Zone-Intrusion Detection/Abnormal Audio Detection/Pet Detection/Fire and Smoke Detection.Detection. |
|
| Interface | ||
| Network | RJ-45 LAN Port | |
| POE | Yes, Built-in POE | |
| General | ||
| Color | White | |
| Accessories | Printed User Manual, Installation Kits, CD or Download Link QR Code Stickers | |
| Power Supply | PoE&DC12V | |
| Work Humidity | 10%-90% | |
| Operation Temperature | -40℃-60℃ | |
| Surge Protection | External/Built-in SPD | |
| Proof | IP67 | |
| Power Consumption | Max. 7W | |
| Size | 92.80*89.84mm | |
| Weight | N.W.: 410g, G.W.: 510g | |
| * We may adopt the backup solution when the main solution chipset is in shortage. | ||
| We reserve the right to change products and specifications without prior notice. This information does not convey any license by any implication or otherwise under any patents or other rights. | ||
